Class 10 / Sandrail Front Suspension

This is the complete front suspension as shown, so you get DXF laser/waterjet cut files plus the 3D models for the full bulkhead assembly. There's a bunch of extras too — King shock models, wheel models, uniball/heim models, and the full MS21250 bolt series for mockup.

Yep — the spindle snout pattern is 8 on 3-3/4", which is common for Kartek and Jamar snouts, and the steering rack mounting is set up for 2.0 and 2.5 racks with 4.5" of throw. Tie rod brackets are included in the files.

It's designed around King pure race shocks (2.0x10" coil-over with 2.5x14" bypass) and the tubes are positioned to clear the coil-over. Other brands may work, but if you're running something specific shoot us an email and we'll help you figure out if it'll fit your build.

These are digital — soon as your payment goes through you get a download link for the DXF cut files. Nothing physical ships.

The Class 10 / Sandrail Front Suspension is $750.00.

This Class 10 / Sandrail Front Suspension is brought to you by Baja Customs. Other off-road and race fabrication designers in the DIY Off Road marketplace include All Co Metal Fab, Armada Engineering, Baker Motorsports, BPforged, Brad Howard Welding and Fabrication, Christopher Reader, CRD, Deuling Design, Dirty BFabwerx, FDFabrication, Izzy Fab, JEH Consulting INC, JRTfab, Master Fab, Mc Will Manufacturing, OffroadCAD-Models, Superioroffroaddesigns and Velocity Fab. Need a custom part designed? Email us and we will connect you with the right designer.

DIY Off Road has downloadable DXF cut files for Complete Bulkhead (Front End) Assemblies plus a ton of other off-road and race fabrication parts, all drawn up by real fab shops. Browse the Complete Bulkhead (Front End) Assemblies category, or shoot us an email and we will point you to the right files for your build.

Yeah — DIY Off Road carries downloadable DXF cut files across Race/Play Chassis Components, including Complete Bulkhead (Front End) Assemblies, all designed by working fab shops. Browse the Race/Play Chassis Components section or email us and we will help you track down the right files.

Yeah — if you don't have your own CNC plasma, laser, or waterjet, shoot us an email and we'll send over a few shops that can cut (and press/bend) the parts so you can weld them up.

Soon as your payment goes through you get a download link for the DXF cut files. You (or a shop) cut them from steel on a plasma, laser, or waterjet, bend whatever needs it, then weld them into your build. Nothing physical ships.

Yep — these are cut files for DIY and pro fabrication. A lot of the parts are "plasma table friendly" (flat plate, no bends) to make cutting and assembly easier, but you'll need to cut and weld them in yourself, or have a shop handle it.
