38" Single Shock Rock Racer Link Arm - PTF
This trailing arm is designed to run a single shock, with shock mounting hole diameter of 1/2" with the option to open the mounting hole to 5/8". Cut out of predominantly 3/16" material, these links don't require bending of plates. Their lower profile layout allows for improved clearance over the trail in the toughest conditions. Designed around the 1" uni-ball bearing wobble stopper kits (front chassis pivot) and 1.25" rod end pack sold on Diyoffroad.com under the fabrication / hard parts section of the site.
***This product is a Digital Asset. You are purchasing the cutting files (DXF) or Solid (CAD) files for this component so that you can have these plates cut and bent (press) from a CNC plasma, laser, or waterjet machine.***
PTF (Plasma Table Friendly) - This means that the component is designed with little to no bends, mostly or all flat plate. This makes the cutting and assembly very easy for anyone with a plasma table. Specific steps are required (follow the WPO) to ensure the strength is kept with this component.
