RZR 2014-17 XP1000 Front Suspension from Allco Fab
This kit widens the trackwidth 3" per side and moves the front suspensoin forward a few inches to increase the wheelbase. It also features 1/2" plate cutfiles for the ball join cups so you can press in your stock or aftermarket balljoints.
***This product is a Digital Asset. You are purchasing the cutting files (DXF) for this component so that you can have these plates cut and bent (press) from a CNC plasma, laser, or waterjet machine.***
More Information
| Seller | TEKK Consulting |
|---|
Specifications
| Platform | Polaris RZR (XP1000 / Turbo / Turbo S / Pro XP / ProR) |
|---|---|
| Part Family | Front A-Arms / Control Arms (UCA / LCA) |
| Position | Front suspension |
| Build System | Long-travel (LT) |
Frequently Asked Questions
These are designed specifically for the 2014-2017 Polaris XP1000. If you've got a different year, shoot us an email and we'll see if there's another file that'll work for your build.
They're designed to be laser cut and CNC bent for tolerance, but you can cut them on a tuned plasma table if your setup is dialed in. Just know the tighter tolerances are what make the fitment work, so a sloppy table will give you headaches.
The fixtures are made for the Imperial Fixture tables available here on DIYoffroad.com, but they'll fit any fixture table with 3/8" mounting holes on a 2" square hole pattern.
These are digital — soon as your payment goes through you get a download link for the DXF cut files. Nothing physical ships.
The RZR 2014-17 XP1000 Front Suspension from Allco Fab is $350.00.
This RZR 2014-17 XP1000 Front Suspension from Allco Fab is brought to you by All Co Metal Fab. Other off-road and race fabrication designers in the DIY Off Road marketplace include Armada Engineering, Baja Customs, Baker Motorsports, BPforged, Brad Howard Welding and Fabrication, Christopher Reader, CRD, Deuling Design, Dirty BFabwerx, FDFabrication, Izzy Fab, JEH Consulting INC, JRTfab, Master Fab, Mc Will Manufacturing, OffroadCAD-Models, Superioroffroaddesigns and Velocity Fab. Need a custom part designed? Email us and we will connect you with the right designer.
DIY Off Road has downloadable DXF cut files for UTV Suspension Kits plus a ton of other off-road and race fabrication parts, all drawn up by real fab shops. Browse the UTV Suspension Kits category, or shoot us an email and we will point you to the right files for your build.
Yeah — DIY Off Road carries downloadable DXF cut files across UTV, including UTV Suspension Kits, all designed by working fab shops. Browse the UTV section or email us and we will help you track down the right files.
Yeah — if you don't have your own CNC plasma, laser, or waterjet, shoot us an email and we'll send over a few shops that can cut (and press/bend) the parts so you can weld them up.
Soon as your payment goes through you get a download link for the DXF cut files. You (or a shop) cut them from steel on a plasma, laser, or waterjet, bend whatever needs it, then weld them into your build. Nothing physical ships.
Yep — these are cut files for DIY and pro fabrication. A lot of the parts are "plasma table friendly" (flat plate, no bends) to make cutting and assembly easier, but you'll need to cut and weld them in yourself, or have a shop handle it.
