45" Single Shock Rock Racer Link Arm - PTF
This trailing arm is designed to run a single shock, with shock mounting hole diameter of 1/2" with the option to open the mounting hole to 5/8". Cut out of predominantly 3/16" material, these links don't require bending of plates. Their lower profile layout allows for improved clearance over the trail in the toughest conditions. Designed around the 1" uni-ball bearing wobble stopper kits (front chassis pivot) and 1.25" rod end pack sold on Diyoffroad.com under the fabrication / hard parts section of the site.
***This product is a Digital Asset. You are purchasing the cutting files (DXF) or Solid (CAD) files for this component so that you can have these plates cut and bent (press) from a CNC plasma, laser, or waterjet machine.***
PTF (Plasma Table Friendly) - This means that the component is designed with little to no bends, mostly or all flat plate. This makes the cutting and assembly very easy for anyone with a plasma table. Specific steps are required (follow the WPO) to ensure the strength is kept with this component.
Frequently Asked Questions
They're designed to be cut predominantly out of 3/16" material. Since this is a PTF (Plasma Table Friendly) design, it's mostly flat plate so you can run it right on your plasma table without any plate bending.
Yep, these are designed around the 1" uni-ball bearing wobble stopper kits for the front chassis pivot and the 1.25" rod end pack. Both are sold on Diyoffroad.com under the fabrication / hard parts section.
They're set up for a 1/2" shock mounting hole, with the option to open it up to 5/8" if your hardware calls for it.
These are digital — soon as your payment goes through you get a download link for the DXF cut files. Nothing physical ships.
The 45" Single Shock Rock Racer Link Arm - PTF is $69.00.
