1990 Bronco Chassis and Suspension Scan CAD Pack

$800.00

In stock

This 1990 Bronco Chassis and Suspension Scan CAD pack will be delivered to you from DIY via email, we will reach out to you after purchase to get you the preferred file format.

This pack includes the following:

1990 Bronco Chassis

Front Beam and Radius Arm Scans

Front Shock/Spring Tower Scan

Rear Spring Hangers

Front Spring Hangers

More Information

More Information
Seller	JEH Consulting INC

Specifications

Platform	Ford Bronco
Part Family	3D Scan / CAD Reference Files
Build System	I-beam / Twin I-Beam (TTB)

Frequently Asked Questions

Are these actual cut files or just 3D scan data for designing my own parts?

These are 3D scan CAD files of the factory chassis and suspension, not DXF cut files. They're meant to give you accurate reference geometry to design your own brackets, mounts, or chassis work around.

What file format do these come in and how do I get them?

After you buy, we'll reach out by email to get you the scans in your preferred file format. Everything is delivered digitally, nothing physical ships.

What's actually included in this scan pack?

You get scans of the 1990 Bronco front beam and radius arm, the front shock/spring tower, and both the front and rear spring hangers. That covers the main front suspension and mounting points for working out your build.

How do I get the 1990 Bronco Chassis and Suspension Scan CAD Pack after I buy it?

These are digital — soon as your payment goes through you get a download link for the DXF cut files. Nothing physical ships.

How much does the 1990 Bronco Chassis and Suspension Scan CAD Pack cost?

The 1990 Bronco Chassis and Suspension Scan CAD Pack is $800.00.

Who designs the 1990 Bronco Chassis and Suspension Scan CAD Pack?

This 1990 Bronco Chassis and Suspension Scan CAD Pack is brought to you by Tekk Consulting Inc. Other off-road and race fabrication designers in the DIY Off Road marketplace include All Co Metal Fab, Armada Engineering, Baja Customs, Baker Motorsports, BPforged, Brad Howard Welding and Fabrication, Christopher Reader, CRD, Deuling Design, Dirty BFabwerx, FDFabrication, Izzy Fab, JEH Consulting INC, JRTfab, Master Fab, Mc Will Manufacturing, OffroadCAD-Models and Superioroffroaddesigns. Need a custom part designed? Email us and we will connect you with the right designer.

Where can I get cut files for 90 Bronco Chassis and Suspension?

DIY Off Road has downloadable DXF cut files for 90 Bronco Chassis and Suspension plus a ton of other off-road and race fabrication parts, all drawn up by real fab shops. Browse the 90 Bronco Chassis and Suspension category, or shoot us an email and we will point you to the right files for your build.

Do you have 3D Scan CAD Files cut files for an off-road or race build?

Yeah — DIY Off Road carries downloadable DXF cut files across 3D Scan CAD Files, including 90 Bronco Chassis and Suspension, all designed by working fab shops. Browse the 3D Scan CAD Files section or email us and we will help you track down the right files.

Can you point me to a shop to get these cut and bent?

Yeah — if you don't have your own CNC plasma, laser, or waterjet, shoot us an email and we'll send over a few shops that can cut (and press/bend) the parts so you can weld them up.

How do I get the files, and what do I do with them?

Soon as your payment goes through you get a download link for the DXF cut files. You (or a shop) cut them from steel on a plasma, laser, or waterjet, bend whatever needs it, then weld them into your build. Nothing physical ships.

Do I need to know how to weld and fab to use these?

Yep — these are cut files for DIY and pro fabrication. A lot of the parts are "plasma table friendly" (flat plate, no bends) to make cutting and assembly easier, but you'll need to cut and weld them in yourself, or have a shop handle it.
