| Seller | TEKK Consulting |
|---|
Specifications
| Platform | Universal / platform-agnostic |
|---|---|
| Part Family | Radius-Arm / Beam Chassis Mounts (caster + offset set) |
| Position | Straight (0 deg) vs angled (10 / 20 / 34 / 45 deg) mount geometry |
| Build System | I-beam / Twin I-Beam (TTB) |
Frequently Asked Questions
Yep, these are designed around 1.25" rod ends with 3/4" bolts and 2" spread spacers. If you're running a different rod end size, shoot us an email and we'll see if there's another file that fits your setup.
Pretty much — this one is PTF (Plasma Table Friendly), so it's mostly or all flat plate with little to no bends, which makes cutting and assembly easy. Just make sure you follow the WPO since there are specific steps to keep the strength in the finished mount.
This is a digital asset, so you're getting the DXF cut files (or CAD solids) to have the plates cut from a CNC plasma, laser, or waterjet. Nothing ships to you — you take the files, have them cut, then assemble and weld into your build.
These are digital — soon as your payment goes through you get a download link for the DXF cut files. Nothing physical ships.
The UNIVERSAL BEAM MOUNT 0" OFFSET is $12.00.
This UNIVERSAL BEAM MOUNT 0" OFFSET is brought to you by Tekk Consulting Inc. Other off-road and race fabrication designers in the DIY Off Road marketplace include All Co Metal Fab, Armada Engineering, Baja Customs, Baker Motorsports, BPforged, Brad Howard Welding and Fabrication, Christopher Reader, CRD, Deuling Design, Dirty BFabwerx, FDFabrication, Izzy Fab, JEH Consulting INC, JRTfab, Master Fab, Mc Will Manufacturing, OffroadCAD-Models and Superioroffroaddesigns. Need a custom part designed? Email us and we will connect you with the right designer.
DIY Off Road has downloadable DXF cut files for Universal Beam and Radius Arm Chassis Mounts plus a ton of other off-road and race fabrication parts, all drawn up by real fab shops. Browse the Universal Beam and Radius Arm Chassis Mounts category, or shoot us an email and we will point you to the right files for your build.
Yeah — DIY Off Road carries downloadable DXF cut files across Universal Beam Components, including Universal Beam and Radius Arm Chassis Mounts, all designed by working fab shops. Browse the Universal Beam Components section or email us and we will help you track down the right files.
Yeah — if you don't have your own CNC plasma, laser, or waterjet, shoot us an email and we'll send over a few shops that can cut (and press/bend) the parts so you can weld them up.
Soon as your payment goes through you get a download link for the DXF cut files. You (or a shop) cut them from steel on a plasma, laser, or waterjet, bend whatever needs it, then weld them into your build. Nothing physical ships.
Yep — these are cut files for DIY and pro fabrication. A lot of the parts are "plasma table friendly" (flat plate, no bends) to make cutting and assembly easier, but you'll need to cut and weld them in yourself, or have a shop handle it.
