42" Universal Radius Arm - Plasma Table Friendly
These Universal Radius Arms are designed to complement the JEHC Universal Beams and feature stout boxed construction with a 1.25" rod end for the chassis mount. They are designed to be "flat", as in there is NO camber built into the radius arm. The camber is built into the universal radius arm mount from JEHC (separate file). Constructed from all 3/16" material this arm is plasma table friendly and will fit on a 4'x4' table with no issues.
***This product is a Digital Asset. You are purchasing the cutting files (DXF) for this component so that you can have these plates cut and bent (press) from a CNC plasma, laser, or waterjet machine.***
Plasma Table Friendly - This means that the component is designed with no bends, all flat plate. This makes the cutting and assembly very easy for anyone with a plasma table. Specific steps are required (follow the WPO) to ensure the strength is kept with this component.
More Information
| Seller | TEKK Consulting |
|---|
Specifications
| Platform | Universal / platform-agnostic |
|---|---|
| Part Family | Radius Arms |
| Position | Front suspension |
| Build System | Plasma Table Friendly (PTF) flat-plate, no-bend |
Frequently Asked Questions
These are designed from 3/16" material across the board. Just cut everything from 3/16" plate and follow the WPO so you keep the strength when you weld it up.
You're good, these are designed to be plasma table friendly and fit on a 4'x4' table with no issues. All flat plate, no bends in the arm itself.
Right, these arms are built flat with no camber on purpose. The camber is built into the JEHC universal radius arm mount, which is a separate file you'll need to run alongside these and the JEHC universal beams.
These are digital — soon as your payment goes through you get a download link for the DXF cut files. Nothing physical ships.
The 42" Universal Radius Arm - Plasma Table Friendly is $42.00.
This 42" Universal Radius Arm - Plasma Table Friendly is brought to you by Tekk Consulting Inc. Other off-road and race fabrication designers in the DIY Off Road marketplace include All Co Metal Fab, Armada Engineering, Baja Customs, Baker Motorsports, BPforged, Brad Howard Welding and Fabrication, Christopher Reader, CRD, Deuling Design, Dirty BFabwerx, FDFabrication, Izzy Fab, JEH Consulting INC, JRTfab, Master Fab, Mc Will Manufacturing, OffroadCAD-Models and Superioroffroaddesigns. Need a custom part designed? Email us and we will connect you with the right designer.
DIY Off Road has downloadable DXF cut files for Universal Radius Arm Setups plus a ton of other off-road and race fabrication parts, all drawn up by real fab shops. Browse the Universal Radius Arm Setups category, or shoot us an email and we will point you to the right files for your build.
Yeah — DIY Off Road carries downloadable DXF cut files across Universal Beam Components, including Universal Radius Arm Setups, all designed by working fab shops. Browse the Universal Beam Components section or email us and we will help you track down the right files.
Yeah — if you don't have your own CNC plasma, laser, or waterjet, shoot us an email and we'll send over a few shops that can cut (and press/bend) the parts so you can weld them up.
Soon as your payment goes through you get a download link for the DXF cut files. You (or a shop) cut them from steel on a plasma, laser, or waterjet, bend whatever needs it, then weld them into your build. Nothing physical ships.
Yep — these are cut files for DIY and pro fabrication. A lot of the parts are "plasma table friendly" (flat plate, no bends) to make cutting and assembly easier, but you'll need to cut and weld them in yourself, or have a shop handle it.
