4.0" Tube 4" Height Upper Link Mount "Angled" (10 deg)
***This product is a Digital Asset, you are purchasing the cutting files (DXF) for this component so that you can have these plates cut and bent (press) from a CNC plasma, laser, or waterjet machine.***
Plasma Table Friendly – This means that the component is designed with no bends, all flat plate. This makes the cutting and assembly very easy for anyone with a plasma table. Specific steps are required (follow the WPO) to ensure the strength is kept with this component.
| Seller | JEH Consulting INC |
|---|
Frequently Asked Questions
These are drawn to mount off a 4.0" tube, so the radius is cut for that size. If you're running a different tube diameter, shoot us an email and we'll see if we have a file that matches your housing.
These need to be press bent after cutting — the DXF is set up so you can run them on a plasma, laser, or waterjet and then bend them in a press. If you don't have a press, email us and we can recommend a shop to cut and bend them for you.
The 10 deg is the angle the mount is set at off the housing tube for your upper link geometry. If you're not sure that angle suits your build, reach out and we can connect you with the designer to dial in what works for your suspension.
These are digital — soon as your payment goes through you get a download link for the DXF cut files. Nothing physical ships.
The 4.0" Tube 4" Height Upper Link Mount "Angled" (10 deg) is $9.00.
