3.25" Tube "Front Mount" (20 deg)
Details
***This product is a Digital Asset, you are purchasing the cutting files (DXF) for this component so that you can have these plates cut and bent (press) from a CNC plasma, laser, or waterjet machine.***
Plasma Table Friendly – This means that the component is designed with no bends, all flat plate. This makes the cutting and assembly very easy for anyone with a plasma table. Specific steps are required (follow the WPO) to ensure the strength is kept with this component.
More Information
| Seller | JEH Consulting INC |
|---|
Specifications
| Platform | Universal / platform-agnostic |
|---|---|
| Part Family | Upper / Lower Link Mounts (housing-mounted) |
| Position | Under-housing vs front-of-housing (lower link mount) |
| Build System | Link suspension (general rod-end / uniball link) |
Frequently Asked Questions
Yep, this one's designed for 3.25" tube, so the saddle is cut to wrap that diameter right out of the box. Just run the DXF on your plasma, laser, or waterjet and it'll match up.
These get bent on a press after you cut them, then welded in — the description covers that you're cutting and bending these from CNC plasma, laser, or waterjet. If you don't have a press, email us and we can point you to a shop that'll cut and bend them for you.
You're buying the DXF cutting files for this 20 degree front lower link mount — nothing physical ships, you take the files to a table to get the plates cut. The file doesn't lock you into a thickness, so cut it from whatever plate suits your link setup; shoot us an email if you want a recommendation for your build.
These are digital — soon as your payment goes through you get a download link for the DXF cut files. Nothing physical ships.
The 3.25" Tube "Front Mount" (20 deg) is $9.00.
