4 Link Mounts 2.75" on 5/8" bolt for Trail-Gear 3.5 Housing - Centered- PTF
This link mount is designed for the Trail-Gear housing center section and setup to be centered on the housing center section and setup for 5/8" pivot bolts and 1.25" rod ends on a 2.75” spread for traditional 4 link setups, both for desert racing and rock racing.
***This product is a Digital Asset. You are purchasing the cutting files (DXF) or Solid (CAD) files for this component so that you can have these plates cut and bent (press) from a CNC plasma, laser, or waterjet machine.***
PTF (Plasma Table Friendly) - This means that the component is designed with little to no bends, mostly or all flat plate. This makes the cutting and assembly very easy for anyone with a plasma table. Specific steps are required (follow the WPO) to ensure the strength is kept with this component.
Details
This link mount is designed for the Trail-Gear housing center section and setup to be centered on the housing center section and setup for 5/8" pivot bolts and 1.25" rod ends on a 2.75” spread for traditional 4 link setups, both for desert racing and rock racing.
***This product is a Digital Asset. You are purchasing the cutting files (DXF) or Solid (CAD) files for this component so that you can have these plates cut and bent (press) from a CNC plasma, laser, or waterjet machine.***
PTF (Plasma Table Friendly) - This means that the component is designed with little to no bends, mostly or all flat plate. This makes the cutting and assembly very easy for anyone with a plasma table. Specific steps are required (follow the WPO) to ensure the strength is kept with this component.
More Information
| Seller | TEKK Consulting |
|---|
Specifications
| Platform | Aftermarket fab housings (Spidertrax / Trail-Gear / Camburg / Currie F9) |
|---|---|
| Part Family | Upper / Lower Link Mounts (housing-mounted) |
| Position | Equal-length / centered / pinion-centered (truss + link-mount positioning) |
| Build System | 4-link rear |
Frequently Asked Questions
Yep, these are designed specifically for the Trail-Gear 3.5" housing center section and they're centered on it. If you're running a different housing, shoot us an email and we'll see if we've got a file that matches your setup.
That's exactly what they're built for — 5/8" pivot bolts and 1.25" rod ends on a 2.75" spread for a traditional 4 link, whether you're going desert or rock racing.
They're PTF (Plasma Table Friendly), so it's mostly or all flat plate with little to no bends — easy to cut and assemble on a plasma table. Just make sure you follow the included WPO so you keep the strength in the part.
These are digital — soon as your payment goes through you get a download link for the DXF cut files. Nothing physical ships.
The 4 Link Mounts 2.75" on 5/8" bolt for Trail-Gear 3.5 Housing - Centered- PTF is $14.00.
This 4 Link Mounts 2.75" on 5/8" bolt for Trail-Gear 3.5 Housing - Centered- PTF is brought to you by Tekk Consulting Inc. Other off-road and race fabrication designers in the DIY Off Road marketplace include All Co Metal Fab, Armada Engineering, Baja Customs, Baker Motorsports, BPforged, Brad Howard Welding and Fabrication, Christopher Reader, CRD, Deuling Design, Dirty BFabwerx, FDFabrication, Izzy Fab, JEH Consulting INC, JRTfab, Master Fab, Mc Will Manufacturing, OffroadCAD-Models and Superioroffroaddesigns. Need a custom part designed? Email us and we will connect you with the right designer.
DIY Off Road has downloadable DXF cut files for Trail Gear 3.5" Housing Link/Truss Setups plus a ton of other off-road and race fabrication parts, all drawn up by real fab shops. Browse the Trail Gear 3.5" Housing Link/Truss Setups category, or shoot us an email and we will point you to the right files for your build.
Yeah — DIY Off Road carries downloadable DXF cut files across Aftermarket Fabricated Housing Link Mounts and Truss Setups, including Trail Gear 3.5" Housing Link/Truss Setups, all designed by working fab shops. Browse the Aftermarket Fabricated Housing Link Mounts and Truss Setups section or email us and we will help you track down the right files.
Yeah — if you don't have your own CNC plasma, laser, or waterjet, shoot us an email and we'll send over a few shops that can cut (and press/bend) the parts so you can weld them up.
Soon as your payment goes through you get a download link for the DXF cut files. You (or a shop) cut them from steel on a plasma, laser, or waterjet, bend whatever needs it, then weld them into your build. Nothing physical ships.
Yep — these are cut files for DIY and pro fabrication. A lot of the parts are "plasma table friendly" (flat plate, no bends) to make cutting and assembly easier, but you'll need to cut and weld them in yourself, or have a shop handle it.
