3 lINK MOUNT FOR TRAIL GEAR HOUSING - CENTERED - PTF
This link mount is designed for the Trail Gear housing center section and setup to be centered on the housing center section and setup for 3/4" pivot bolt and 1.25" rod end on a 2.75” spread for traditional 3 link setups, both for desert racing and rock racing.
***This product is a Digital Asset. You are purchasing the cutting files (DXF) or Solid (CAD) files for this component so that you can have these plates cut and bent (press) from a CNC plasma, laser, or waterjet machine.***
PTF (Plasma Table Friendly) - This means that the component is designed with little to no bends, mostly or all flat plate. This makes the cutting and assembly very easy for anyone with a plasma table. Specific steps are required (follow the WPO) to ensure the strength is kept with this component.
This link mount is designed for the Trail Gear housing center section and setup to be centered on the housing center section and setup for 3/4" pivot bolt and 1.25" rod end on a 2.75” spread for traditional 3 link setups, both for desert racing and rock racing.
***This product is a Digital Asset. You are purchasing the cutting files (DXF) or Solid (CAD) files for this component so that you can have these plates cut and bent (press) from a CNC plasma, laser, or waterjet machine.***
PTF (Plasma Table Friendly) - This means that the component is designed with little to no bends, mostly or all flat plate. This makes the cutting and assembly very easy for anyone with a plasma table. Specific steps are required (follow the WPO) to ensure the strength is kept with this component.
Frequently Asked Questions
Yep, it's designed for a 3/4" pivot bolt and a 1.25" rod end on a 2.75" spread. That's a pretty standard setup for a traditional 3 link, whether you're running desert or rock racing.
It's PTF (Plasma Table Friendly), so it's mostly or all flat plate with little to no bends — easy to cut and assemble on a plasma table. Just make sure you follow the WPO so you keep the strength in the part.
This one's designed specifically for the Trail Gear housing center section and set up to be centered on it. If you're running a different housing, shoot us an email and we'll see if we've got a file that works for your build.
These are digital — soon as your payment goes through you get a download link for the DXF cut files. Nothing physical ships.
The 3 lINK MOUNT FOR TRAIL GEAR HOUSING - CENTERED - PTF is $14.00.
