Universal Y Frame Fixture with 82" Tekk Table (Combo Pack)
***This product is a Digital Asset. You are purchasing the cutting files (DXF) for this component so that you can have these plates cut and bent (press) from a CNC plasma, laser, or waterjet machine.***
Frequently Asked Questions
You get the DXF cut files for both the Universal Y Frame fixture and the 82"x30" Imperial 2"x2" pattern Tekk Table (part 104-JLF-013). Take both files, have the plates cut on a plasma, laser, or waterjet, then bend the press parts and you're set up to build.
This setup handles Y-Frame builds up to 145" wheelbase and 74"-98" track width, so it covers just about any truck application. If your build is outside that range, email us and we'll see if another file works for you.
Yep, this fixture is designed for building tube Y-Frame assemblies with the various Tekk bulkheads and rear pivot boxes. Have the plates cut and bent, weld up your fixture, and you're ready to jig your Y-frame.
These are digital — soon as your payment goes through you get a download link for the DXF cut files. Nothing physical ships.
The Universal Y Frame Fixture with 82" Tekk Table (Combo Pack) is $424.00.
The Universal Y Frame Fixture with 82" Tekk Table (Combo Pack) is offered through the DIY Off Road marketplace, featuring cut-file designs from fabricators including All Co Metal Fab, Armada Engineering, Baja Customs, Baker Motorsports, BPforged, Brad Howard Welding and Fabrication, Christopher Reader, CRD, Deuling Design, Dirty BFabwerx, FDFabrication, Izzy Fab, JEH Consulting INC, JRTfab, Master Fab, Mc Will Manufacturing, OffroadCAD-Models and Superioroffroaddesigns. Need a custom part designed? Email us and we will connect you with the right designer.
DIY Off Road has downloadable DXF cut files for Imperial JEHC Tables plus a ton of other off-road and race fabrication parts, all drawn up by real fab shops. Browse the Imperial JEHC Tables category, or shoot us an email and we will point you to the right files for your build.
Yeah — DIY Off Road carries downloadable DXF cut files across JEHC Fixture Tables, including Imperial JEHC Tables, all designed by working fab shops. Browse the JEHC Fixture Tables section or email us and we will help you track down the right files.
Yeah — if you don't have your own CNC plasma, laser, or waterjet, shoot us an email and we'll send over a few shops that can cut (and press/bend) the parts so you can weld them up.
Soon as your payment goes through you get a download link for the DXF cut files. You (or a shop) cut them from steel on a plasma, laser, or waterjet, bend whatever needs it, then weld them into your build. Nothing physical ships.
Yep — these are cut files for DIY and pro fabrication. A lot of the parts are "plasma table friendly" (flat plate, no bends) to make cutting and assembly easier, but you'll need to cut and weld them in yourself, or have a shop handle it.
