1450mmx750mm METRIC 50mmx50mm Pattern Table

The files give you the 1450x750mm honeycomb top with the 50x50mm 10mm bolt pattern, but we don't spec a set plate thickness here. Most guys pick their top thickness based on how heavy they're building the table, so cut it from whatever plate suits your setup, or email us and we'll point you in the right direction.

This one is the metric version, 1450x750mm with a 50mm by 50mm pattern using 10mm through bolts. If you need an imperial layout instead, shoot us an email and we'll see if we've got a file that fits what you're after.

This is the honeycomb fixture top with the 50x50mm bolt pattern. It doesn't include a base or leg files, so you'll want to build or source a frame to mount it to once you've had the top cut.

These are digital — soon as your payment goes through you get a download link for the DXF cut files. Nothing physical ships.

The 1450mmx750mm METRIC 50mmx50mm Pattern Table is $82.00.

The 1450mmx750mm METRIC 50mmx50mm Pattern Table is offered through the DIY Off Road marketplace, featuring cut-file designs from fabricators including All Co Metal Fab, Armada Engineering, Baja Customs, Baker Motorsports, BPforged, Brad Howard Welding and Fabrication, Christopher Reader, CRD, Deuling Design, Dirty BFabwerx, FDFabrication, Izzy Fab, JEH Consulting INC, JRTfab, Master Fab, Mc Will Manufacturing, OffroadCAD-Models and Superioroffroaddesigns. Need a custom part designed? Email us and we will connect you with the right designer.

DIY Off Road has downloadable DXF cut files for Metric JEHC Tables plus a ton of other off-road and race fabrication parts, all drawn up by real fab shops. Browse the Metric JEHC Tables category, or shoot us an email and we will point you to the right files for your build.

Yeah — DIY Off Road carries downloadable DXF cut files across JEHC Fixture Tables, including Metric JEHC Tables, all designed by working fab shops. Browse the JEHC Fixture Tables section or email us and we will help you track down the right files.

Yeah — if you don't have your own CNC plasma, laser, or waterjet, shoot us an email and we'll send over a few shops that can cut (and press/bend) the parts so you can weld them up.

Soon as your payment goes through you get a download link for the DXF cut files. You (or a shop) cut them from steel on a plasma, laser, or waterjet, bend whatever needs it, then weld them into your build. Nothing physical ships.

Yep — these are cut files for DIY and pro fabrication. A lot of the parts are "plasma table friendly" (flat plate, no bends) to make cutting and assembly easier, but you'll need to cut and weld them in yourself, or have a shop handle it.
