950mmx750mm METRIC 50mmx50mm Pattern JEHC Table
Frequently Asked Questions
The files are designed around the 950mm x 750mm table size with the 50mm x 50mm hole pattern. You'll just download the DXF and have it cut on your plasma, laser, or waterjet — nesting onto your sheet is up to you and your cutter.
Yep, this pattern is built for 10mm through bolts on a 50mm by 50mm grid, so it's all metric. Run 10mm hardware and you're good.
The files give you the honeycomb pattern, but the plate thickness is your call based on your build and your cutter. If you want a recommendation, shoot us an email and we can point you in the right direction or connect you with the designer.
These are digital — soon as your payment goes through you get a download link for the DXF cut files. Nothing physical ships.
The 950mmx750mm METRIC 50mmx50mm Pattern JEHC Table is $72.00.
The 950mmx750mm METRIC 50mmx50mm Pattern JEHC Table is offered through the DIY Off Road marketplace, featuring cut-file designs from fabricators including All Co Metal Fab, Armada Engineering, Baja Customs, Baker Motorsports, BPforged, Brad Howard Welding and Fabrication, Christopher Reader, CRD, Deuling Design, Dirty BFabwerx, FDFabrication, Izzy Fab, JEH Consulting INC, JRTfab, Master Fab, Mc Will Manufacturing, OffroadCAD-Models and Superioroffroaddesigns. Need a custom part designed? Email us and we will connect you with the right designer.
DIY Off Road has downloadable DXF cut files for Metric JEHC Tables plus a ton of other off-road and race fabrication parts, all drawn up by real fab shops. Browse the Metric JEHC Tables category, or shoot us an email and we will point you to the right files for your build.
Yeah — DIY Off Road carries downloadable DXF cut files across JEHC Fixture Tables, including Metric JEHC Tables, all designed by working fab shops. Browse the JEHC Fixture Tables section or email us and we will help you track down the right files.
Yeah — if you don't have your own CNC plasma, laser, or waterjet, shoot us an email and we'll send over a few shops that can cut (and press/bend) the parts so you can weld them up.
Soon as your payment goes through you get a download link for the DXF cut files. You (or a shop) cut them from steel on a plasma, laser, or waterjet, bend whatever needs it, then weld them into your build. Nothing physical ships.
Yep — these are cut files for DIY and pro fabrication. A lot of the parts are "plasma table friendly" (flat plate, no bends) to make cutting and assembly easier, but you'll need to cut and weld them in yourself, or have a shop handle it.
