5x5' (1350x1350mm) Metric 10mm Bolt on 50x50mm Spread (5mm plate material)
These JEHC Table sections are designed to be either used individually or bolted/welded together to make a full chassis table in 5′ sections. From 10′, 15′, and 20′ sections. These honeycomb sections are easy to build and offer a great platform to build a chassis off of.
***This product is a Digital Asset. You are purchasing the cutting files (DXF) for this component so that you can have these plates cut and bent (press) from a CNC plasma, laser, or waterjet machine.***
Frequently Asked Questions
Yeah, these are made to bolt or weld together into longer chassis tables, so you can run them in 5' sections up to 10', 15', or 20'. This file gets you one 5x5' section, so just grab as many as you need for the length you want.
This set is designed to be cut from 5mm plate material. Run the DXF on your plasma, laser, or waterjet and you're good to go.
This version is the metric setup with 10mm bolt holes on a 50x50mm spread. So source your hardware to match before you start bolting sections together.
These are digital — soon as your payment goes through you get a download link for the DXF cut files. Nothing physical ships.
The 5x5' (1350x1350mm) Metric 10mm Bolt on 50x50mm Spread (5mm plate material) is $225.00.
