2019 RZR 1000 Turbo Upper Arm Scan

This one's scan data, not a cut file — you get the scan mesh in STEP format plus geometry blocks so you can pull center points and key measurements for your own design. It's meant as a starting point to design your own upper arms, not something you run straight on the plasma table.

Any CAD program that handles STEP files will open it — Fusion 360, SolidWorks, Inventor, that kind of thing. The geometry blocks come along with the mesh so you can reference center points and relevant data right in your CAD.

This pack is scanned off a 2019 RZR XP1000 Turbo, so that's what it's confirmed for. If you're running a different year and want to know how close it'll be, shoot us an email and we'll see if it works for your build or if there's another scan that fits better.

These are digital — soon as your payment goes through you get a download link for the DXF cut files. Nothing physical ships.

The 2019 RZR 1000 Turbo Upper Arm Scan is $100.00.

This 2019 RZR 1000 Turbo Upper Arm Scan is brought to you by Tekk Consulting Inc. Other off-road and race fabrication designers in the DIY Off Road marketplace include All Co Metal Fab, Armada Engineering, Baja Customs, Baker Motorsports, BPforged, Brad Howard Welding and Fabrication, Christopher Reader, CRD, Deuling Design, Dirty BFabwerx, FDFabrication, Izzy Fab, JEH Consulting INC, JRTfab, Master Fab, Mc Will Manufacturing, OffroadCAD-Models and Superioroffroaddesigns. Need a custom part designed? Email us and we will connect you with the right designer.

DIY Off Road has downloadable DXF cut files for 2019 Rzr XP1000 Turbo plus a ton of other off-road and race fabrication parts, all drawn up by real fab shops. Browse the 2019 Rzr XP1000 Turbo category, or shoot us an email and we will point you to the right files for your build.

Yeah — DIY Off Road carries downloadable DXF cut files across 3D Scan CAD Files, including 2019 Rzr XP1000 Turbo, all designed by working fab shops. Browse the 3D Scan CAD Files section or email us and we will help you track down the right files.

Yeah — if you don't have your own CNC plasma, laser, or waterjet, shoot us an email and we'll send over a few shops that can cut (and press/bend) the parts so you can weld them up.

Soon as your payment goes through you get a download link for the DXF cut files. You (or a shop) cut them from steel on a plasma, laser, or waterjet, bend whatever needs it, then weld them into your build. Nothing physical ships.

Yep — these are cut files for DIY and pro fabrication. A lot of the parts are "plasma table friendly" (flat plate, no bends) to make cutting and assembly easier, but you'll need to cut and weld them in yourself, or have a shop handle it.
