5' x 10' Chassis Table with 2"x 2" Pattern

$800.00

In stock

SKU

104-JEH-014

This Chassis table is designed for building large weldment structures with accuracy. Utilizing a standard 2”x2” pattern and holes lasered to the perfect diameter for a 3/8” tap, this table is a great addition to any professional fabrication facility. Featuring a main structure from 2x3” .250 wall material with a 3/8” main plate and cross ribbing this table can hold plenty of weight accurately.

The 4 feet are designed for ¾” shank adjustable casters or solid mounts. The tables are also designed with alignment pins (standard 1” from Mcmaster) machined to perfection for the exact fit, when stacking tables together you can easily align them and bolt them for that perfect bolt pattern extension. This allows for the continuation of the bolt pattern across the distance of the table (usually 20’) when fixturing larger weldments like a race truck chassis.

All the tubes are designed to be laser cut with tab/slot style interlocking for the perfect fitment during fabrication of the table, including the tubes. Contact Us for any questions on where to get this cut.

***This product is a Digital Asset. You are purchasing the cutting files (DXF) for this component so that you can have these plates cut and bent (press) from a CNC plasma, laser, or waterjet machine.***

Frequently Asked Questions

Are the tube parts in these files set up to interlock, or do I have to jig everything myself when I weld it up?

The tubes are designed with tab/slot style interlocking so everything self-fixtures for perfect fitment while you weld the table together. Makes assembly way easier and keeps it accurate.

Can I bolt two of these together to fixture a full-length trophy truck chassis?

Yep, that's the idea. The files include machined alignment pin locations (standard 1" from McMaster) so you can stack and bolt tables together and continue the 2"x2" bolt pattern across the distance, usually out to around 20' for fixturing a race truck chassis.

What do I get when I buy this, and what machine do I need to cut it on?

You're getting the DXF cut files for the plates and tubes, not a physical table. They're set up for CNC plasma, laser, or waterjet, but since the holes are lasered to size for a 3/8" tap and the tubes use tab/slot interlocks, laser is ideal — hit us up if you need a recommendation on where to get them cut.

How do I get the 5' x 10' Chassis Table with 2"x 2" Pattern after I buy it?

These are digital — soon as your payment goes through you get a download link for the DXF cut files. Nothing physical ships.

How much does the 5' x 10' Chassis Table with 2"x 2" Pattern cost?

The 5' x 10' Chassis Table with 2"x 2" Pattern is $800.00.

Who designs the 5' x 10' Chassis Table with 2"x 2" Pattern?

The 5' x 10' Chassis Table with 2"x 2" Pattern is offered through the DIY Off Road marketplace, featuring cut-file designs from fabricators including All Co Metal Fab, Armada Engineering, Baja Customs, Baker Motorsports, BPforged, Brad Howard Welding and Fabrication, Christopher Reader, CRD, Deuling Design, Dirty BFabwerx, FDFabrication, Izzy Fab, JEH Consulting INC, JRTfab, Master Fab, Mc Will Manufacturing, OffroadCAD-Models and Superioroffroaddesigns. Need a custom part designed? Email us and we will connect you with the right designer.

Where can I get cut files for JEHC Race Chassis Tables?

DIY Off Road has downloadable DXF cut files for JEHC Race Chassis Tables plus a ton of other off-road and race fabrication parts, all drawn up by real fab shops. Browse the JEHC Race Chassis Tables category, or shoot us an email and we will point you to the right files for your build.

Do you have JEHC Fixture Tables cut files for an off-road or race build?

Yeah — DIY Off Road carries downloadable DXF cut files across JEHC Fixture Tables, including JEHC Race Chassis Tables, all designed by working fab shops. Browse the JEHC Fixture Tables section or email us and we will help you track down the right files.

Can you point me to a shop to get these cut and bent?

Yeah — if you don't have your own CNC plasma, laser, or waterjet, shoot us an email and we'll send over a few shops that can cut (and press/bend) the parts so you can weld them up.

How do I get the files, and what do I do with them?

Soon as your payment goes through you get a download link for the DXF cut files. You (or a shop) cut them from steel on a plasma, laser, or waterjet, bend whatever needs it, then weld them into your build. Nothing physical ships.

Do I need to know how to weld and fab to use these?

Yep — these are cut files for DIY and pro fabrication. A lot of the parts are "plasma table friendly" (flat plate, no bends) to make cutting and assembly easier, but you'll need to cut and weld them in yourself, or have a shop handle it.
