Wildcat XX Prep Cart - Cutfiles - DXF
This prep cart is designed to hold up the XX with the drivetrain in place and allow you to prep the entier chassis, susopenion cycle incluided. This is the same as what JEHC INC uses for the AWD unilimted class platforms as well.
***This product is a Digital Asset. You are purchasing the cutting files (DXF) or Solid (CAD) files for this component so that you can have these plates cut and bent (press) from a CNC plasma, laser, or waterjet machine.***
Frequently Asked Questions
These are DXF cut files, so you supply your own material when you run them on a plasma, laser, or waterjet. We don't list a specific thickness in the file, so shoot us an email and we'll point you to what's worked for this cart so it holds up the chassis safely.
Some of these plates are designed to be bent in a press after cutting, which is why we offer both the DXF flat patterns and CAD files. If you don't have a press, email us and we can recommend a shop to cut and bend the parts for you.
Yep, this is the same cart JEHC INC uses for their AWD unlimited class platforms, so it lets you prep the whole chassis with suspension cycle included. After payment you just get the digital DXF/CAD files to have cut and built up.
These are digital — soon as your payment goes through you get a download link for the DXF cut files. Nothing physical ships.
The Wildcat XX Prep Cart - Cutfiles - DXF is $75.00.
This Wildcat XX Prep Cart - Cutfiles - DXF is brought to you by Tekk Consulting Inc. Other off-road and race fabrication designers in the DIY Off Road marketplace include All Co Metal Fab, Armada Engineering, Baja Customs, Baker Motorsports, BPforged, Brad Howard Welding and Fabrication, Christopher Reader, CRD, Deuling Design, Dirty BFabwerx, FDFabrication, Izzy Fab, JEH Consulting INC, JRTfab, Master Fab, Mc Will Manufacturing, OffroadCAD-Models and Superioroffroaddesigns. Need a custom part designed? Email us and we will connect you with the right designer.
DIY Off Road has downloadable DXF cut files for Wildcat XX Components plus a ton of other off-road and race fabrication parts, all drawn up by real fab shops. Browse the Wildcat XX Components category, or shoot us an email and we will point you to the right files for your build.
Yeah — DIY Off Road carries downloadable DXF cut files across UTV, including Wildcat XX Components, all designed by working fab shops. Browse the UTV section or email us and we will help you track down the right files.
Yeah — if you don't have your own CNC plasma, laser, or waterjet, shoot us an email and we'll send over a few shops that can cut (and press/bend) the parts so you can weld them up.
Soon as your payment goes through you get a download link for the DXF cut files. You (or a shop) cut them from steel on a plasma, laser, or waterjet, bend whatever needs it, then weld them into your build. Nothing physical ships.
Yep — these are cut files for DIY and pro fabrication. A lot of the parts are "plasma table friendly" (flat plate, no bends) to make cutting and assembly easier, but you'll need to cut and weld them in yourself, or have a shop handle it.
