1.5x1.5 Square Tube Miter Plate Packet
***These products are Digital Assets. You are purchasing the cutting files (DXF) for this component so that you can have these plates cut and bent (press) from a CNC plasma, laser, or waterjet machine.***
| Seller | JEH Consulting INC |
|---|
Frequently Asked Questions
The packet is named for 1.5x1.5 square tube, but heads up — the description text mentions 2x2, so shoot us an email before you buy and we'll confirm exactly which tube size these files are cut for so you don't run the wrong ones on your table.
The packet includes files for the two common walls, .19 and .125, so you should be covered for most square tube builds. The filenames are denoted by thickness so you can grab the right one for your tube.
You get plates for tube angles from 60-120° in 5° steps, plus straight end-caps and straight miters. Each plate works for a joint +/- 5°, so you don't have to hit it dead on — just pick the closest one to your miter.
These are digital — soon as your payment goes through you get a download link for the DXF cut files. Nothing physical ships.
The 1.5x1.5 Square Tube Miter Plate Packet is $8.00.
